EMR – Monorail-shuttle
EXPERT-TÜNKERS | Ensidig skyttel
EXPERT-TÜNKERS Monorail-Shuttle är en kompakt transportlösning för sammanlänkad drift. Den är utformad för att hantera små delar i body in white-produktionen. Systemets vertikala slag tillhandahålls av standard EXPERT-TÜNKERS rullbanelyft. För den synkroniserade, exakta och smidiga horisontella transporten från station till station använder konstruktionen vanliga elektromekaniska linjära axlar.
EMR | MONORAIL-SHUTTLE
The EXPERT-TÜNKERS Monorail-Shuttle is a compact conveying solution for the interlinked operation. It is designed to handle small sized parts in the body-in-white production. The vertical stroke of the system is provided by standard EXPERT-TÜNKERS lift columns. For the synchronized, precise and smooth horizontal transport from station to station, the design utilizes standard electro-mechanical linear axes.
ADVANTAGES OF THE DUORAIL-SHUTTLE-SYSTEM
- Optimized cycle times
- High durability, reduced maintenance
- System based on standardized components
- Economically favourable solution
ADVANTAGES OF THE VERTICAL DRIVE:
The vertical drive of the duroail-shuttle system is based on EXPERT-TÜNKERS standard lift columns.
- Durable and proven drive conept via cylindrical cam and cam follower
- Smooth and jerk-free movement
- Gentle part pickup at v= 0 m/s
- Optimized motion-profile according to VDI-Guidance No. 2143
- Reduced drive power required
- Precise positive locking in upper and lower cam end position.
ADVANTAGES OF THE HORIZONTAL DRIVE
The horizontal drive of the duroail-shuttle system is based on standard electro-mechanical linear axes.
- High flexibility due to customizable station length
- Various transportation speeds due to servo-gearmotor
- High durability due to appropriate aluminum profile dimensions and integrated linear roller guidance
- Reduced maintenance due to lifetime lubricated rollers
- Welding-resistant coverage of transportation belt
REFERENCEN
- Audi Ingolstadt
- Audi Changchun (China)
- Audi San José Chiapa (Mexico)
- Seat Martorell (Spanien)
- Volkswagen Taubaté (Brasilien)
- Volkswagen Anchieta (Brasilien)
Downloads
Technical Data
| Variable | Max. Value |
|---|---|
| Customer Load – [per Station] | 10 – 250 kg |
| Horizontal Stroke | 1.000 – 5.000 mm |
| Vertical Stroke | 300 – 1.500 mm |
| Cycle Time – [Lifting-Transporting-Lowering] | ≥ 5 s |
